CROSS CUT EXFOLIATION TESTER

Standard Method : JIS-D0202, (K5400), K5600-5-6, ISO-2409

This tester is a fully automated cross cutting machine capable of applying crosscuts in a grid pattern on paint coated surfaces, according to the Cross Cut Method.

The perpendiculary set balade is set on the surface of the test specimen,and applied force. The test conditions are set so as all cuts reach the base material, and after cutting, the specimen is brushed , covered with tape, and then peeled within 5 minutes, and evaluated of the result.

The number of scratchs and pitch can be set via touchi panel with No.551-AUTO-1, and 90°automatic rotation is added with No.551-AUTO-2.Both testers are more accurate than manual cross cutting.

Spesifikasi

Model	No.551-AUTO-1	No.551-AUTO-2
Specimen Table	240 × 200 mm	240 × 200 mm
90° Rotation	Manual	Automatic
Max. Specimen Size	210 × 200 mm (Cross Cut Area 140 × 140 mm)	210 × 200 mm (Cross Cut Area 140 × 140 mm)
Scratching Pitch	Chosen from 0.5, 1.0, 1.5, 2.0 mm	Chosen from 0.5, 1.0, 1.5, 2.0 mm
Scratching Number	Variable by Touch Panel (Standard: 6, 11 lines)	Variable by Touch Panel (Standard: 6, 11 lines)
Scratching Speed	5 to 150 mm/s (Unit 0.1 mm/s)	5 to 150 mm/s (Unit 0.1 mm/s)
Test Load	Deadweight Balance + Additional Weights Chosen from 10 to 400 gf, 50 to 1,050 gf	Deadweight Balance + Additional Weights Chosen from 10 to 400 gf, 50 to 1,050 gf
Scratcher	Cutter	Cutter
Safety Device	Emergency Stop SW	Emergency Stop SW
Accessories	Weight*, Spirit Level, Height Adjustment Gauge, Cutter Blade Holder, Spare Cutter Blade, Cutter Blade Setting Jig, Hexagon Wrench, Spanner Wrench	Weight*, Spirit Level, Height Adjustment Gauge, Cutter Blade Holder, Spare Cutter Blade, Cutter Blade Setting Jig, Hexagon Wrench, Spanner Wrench
Option	Needle, Needle Holder, Sapphire Needle, Sapphire Needle Holder, Safety Cover	Needle, Needle Holder, Sapphire Needle, Sapphire Needle Holder, Safety Cover
Power Source	AC 100 V, 1-Phase, 10 A, 50/60 Hz AC 220 V, 1-Phase, 5 A, 50/60 Hz	AC 100 V, 1-Phase, 10 A, 50/60 Hz AC 220 V, 1-Phase, 5 A, 50/60 Hz
Dimensions/ Weight (Approx.)	Safety Cover Not Attached W600 × D750 × H700 mm/ 65 kg Safety Cover Not Attached W630 × D750 × H760 mm/ 75 kg	Safety Cover Not Attached W600 × D750 × H700 mm/ 70 kg Safety Cover Not Attached W630 × D750 × H760 mm/ 80 kg
