​PARTICLE SIZE ANALYSIS OF SOILS HYDROMETER METHOD

Code : S155 KIT

Standard Method : ASTM D422 / AASHTO T88

PARTICLE SIZE ANALYSIS OF SOILS HYDROMETER METHOD

This complete set is used to determine the quantitative size distribution of very fine particle in soils such as clay and silt.

S155 KIT The complete set comprises:

S155-01 Hydrometer jar, 1000 ml capacity (6 pieces provided with the kit)

V172 Soil hydrometer, 151H, range 0.995 to 1.038 g/ml with div. 0.001

S155-04 Glass tank, dimensions: 600x300x380 mm

S155-09 Heater, professional type, complete with thermostat,cooling coil, water circulating unit. 230V 1ph 50-60Hz 1000W

S155-10 Thermometer, range 0 - 50 °C, subdiv. 0.5 °C.

V104-03 Beaker, pyrex, 250 ml capacity

V300-23 Sodium Hexametaphosphate, 1000 g

S156-01 KIT High speed stirrer, 10.000 rpm, complete with cup, paddle, anti-splash baffle, for dispersing soil particles in water.

Power supply : 230V 1ph 50-60Hz

Total weight : 60 kg approx.

ALTERNATIVE:

S155S KIT

PARTICLE SIZE ANALYSIS OF SOIL

Same as S155 KIT but: S155-09S HEATER simple type, complete with thermostat and water circulating unit but without cooling coil (see accessories S155-08). 230V 1ph 50-60Hz

ACCESSORIES

V172-02 SOIL HYDROMETER 152H, range -5 to 60 g/l (alternative to mod. V172)

S155-02 BUNG, rubber, for the cylinder S155-01

S155-08 COOLING COIL for S155-09S

S155-11 NOMOGRAPHIC CHART, for stoke's law determination.

S156 STIRRER, manual, for cylinders 1000 ml capacity mod. S155-01

C306-03 SEPARATE CONTROL PANEL, complete with on/off switch and electric protections, to get S155-09 heater to CE Safety Directive.

ACCESSORIES according to NF P94-057 Standard

S155-03 HYDROMETER JAR, 2500 ml capacity,85 ± 5 mm Ø, graduated at 500, 1500, 2000 ml.

S156-03 STIRRER MANUAL, 600 mm long for cylinders 2500 ml capacity, mod. S155-03.

V172-03 SOIL HYDROMETER 0.995 to 1030 g/ml.

SPARES for S156-01 KIT Stirrer

S156-11 Anti-splash baffle

S156-12 Paddle

S156-13 Cup (beaker)

Untuk mengetahui lebih detail model/type dan spesifikasi dari Matest - PARTICLE SIZE ANALYSIS OF SOILS HYDROMETER METHOD silahkan click link/tautan yang ada di bawah ini :

Click Here Particle Size Analysis Of Soils Hydrometer Method
