YASUDA SEIKI No.275 William Type Abrasion Tester
Harga : Rp 0.00 Rp 0.00
Brand : YASUDA SEIKI,TESTEX,GESTER INST,COMETECH,TOYOSEIKI and etc
Stok : In Stock
YASUDA SEIKI No.275 William Type Abrasion Tester
YASUDA SEIKI No.275 William Type Abrasion Tester
- No.275 William Type Abrasion Tester
- Standard Method : JIS-K6264, ISO-4649
- This tester is to evaluate the abrasion resistance of vulcanized rubber and thermo-plastic rubber. The operator is to determine the volume loss due to the abrasive action of rubbing two flat and non rotating test specimens to an abrading wheel. This tester is usually used on test specimens that are applied for tires and shoe soles.
| No.275 William Type Abrasion Tester | |
| Specification | |
| Specimen | (20+0.5) x (20+0.5) x T10mm |
| Specimen Position | Left-Right 63.5mm from Center of Wheel |
| Test Load | 35.5N (3.62kgf) |
|
Abrasion Wheel |
Outer Dia.165mm, Inner Dia.70mm, Material: C, Grit #70 |
| Wheel Rotation Speed | 37+3rpm |
| Air Nozzle | Vent Dia.1.0mm (Pitch 6mm). Upper & Lower 3pcs each, |
| Pressure Gauge | Air Pressure 180kPa Max. 1MPa (Scale 0.1MPa) |
| Timer | Max. 99min 59sec |
| Accessory | Specimen Cutter |
| Power Source | 100V 1-Phase 10A 50/60Hz |
| Air Source | 0.5MPa or More |
| Dimensions / Weight (Approx.) |
W700xD520xH560 mm / 55kg |
