No.183-S FALLING DART IMPACT TESTER

Harga : Rp 0.00

Brand : Lokal,Impor,Yasuda Seiki,Zwick,Shimadzu,Saumya,Qualitest

Stok : In Stock




No.183-S FALLING DART IMPACT TESTER
  • No.183-S FALLING DART IMPACT TESTER
  • Standard JIS-K6742 ; K6743
  • This tester is used to evaluate the impact resistance of impact resistance hard vinyl chloride pipe (HIVP) and hard vinyl chloride pipe joint (HITS). The operator is to observe the destruction status of the test specimen after it has been hit by a falling weight that fell from a given testing height.

No.183-S FALLING DART IMPACT TESTER


Click Here : Catalog No.183-S Falling Dart Impact Tester


No.183-S FALLING DART IMPACT TESTER
Specification

Falling Dart

 Flat Cylinder Bottom : Mass 1 kg, 3 kg, 9 kg
(3 kinds) Circular Cone: Mass 9 kg
Receiver Flat type, V type (2 kinds)
Falling Height 100 to Max 2,000 mm
Falling Device Solenoid Coil
Repeated Impact
Prevention Device		 Ratchet-Operated
Power Source AC 100 V, 1-Phase, 15 A, 50/60 Hz
Dimension / Weight (Approx.) W800 × D800 × H3,000 mm, 200 kg


Berikut adalah Material Testing Equipment yang kami miliki berikut adalah link / tautan produk sebagai berikut :



No.183-S FALLING DART IMPACT TESTER


Click Here : Catalog No.183-S Falling Dart Impact Tester
